PGM22
Pro Walk-Behind Reel Mower
Jake's Take
The Lightest Mower of its Kind
The PGM22 gives you Jake’s Signature Cut trusted by generations. User-friendly features make it simple to set up and operate, and robust engineering gives you the dependability you need to produce greens you’re proud of every day.
Key Features
Sheet
Professional Level of Cut
Honda® Engine
InCommand™ Operator Controls
Technical Specs
Choose a Section
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
Key Attributes
Reels and Blades
Traction, Brakes and Speed
Weight and Dimensions
| Mower Cutting Width | 22" (0.55 m) |
| Mower Height of Cut | 0.062 - 0.438" (1.6 - 11.1 mm) |
| Blades per Reel | 11 or 15 |
| Mower Engine | Honda® GX-120 Gas Engine |
| Fuel/Battery Capacity | 0.66 gal. (2.5 L) |
| Power | 4 HP (2.9 kW) |
| Sound Level | 95 dBA |
| Mower Warranty | 2 Years |
| Blade Material | Electronically controlled fully adjustable, 0-2200 RPM maximum |
| Reel Speed | Dependent on Engine RPM and 2.25:1 reel reduction ration |
| Frequency of Clip | 13/64" (0.5 cm) |
| Mower Drive System | Centrifugal Drive Clutch |
| Traction Drive | Chain Drive |
| Operator Presence Control | Standard InCommand™ operator controls (Traction and Reel) with integrated Operator Presence Control |
| Differential | Full automotive type, housed in traction drum |
| Traction Drum | 7.75" (19.68 cm) diameter smooth machined aluminum |
| Brakes | Lever actuated hub brake with parking lock |
| Transport Wheels | 2 x Pneumatic 11" x 4" (27.94 x 10 cm) |
| Mowing Speed | Dependent on Engine RPM 3.2 mph (5.14 kph) max |
| Weight | 11 blade reel: 184 lbs. (83.4 kg), 15 blade reel: 194 lbs. (88 kg) (with Catcher, grooved steel roller and Kickstand) |
Engine horsepower may vary due to conditions of specific use. Product available in selected countries. Not available in China.
