HM600
WIDE AREA MULCHING FLAIL MOWER
Jake's Take
A fine finish for the toughest turf
The HM600 has been built in collaboration with Müthing® to deliver a robust, reliable mower with the ability to tackle the toughest jobs, and the finesse to maneuver in tight spaces while providing a quality after-cut appearance.
Learn More About the HM600
Watch
Video
Zaanse Golf Club Go Dutch with Jacobsen HM600 Wide Area Flail Mower
Watch
Video
Delfland Golf Club Holland Get the Aftercut Appearance They Need from HM600 Flail Mower
Watch
Video
Key Features
A TRUSTED MÜTHING® TRIPLE FLAIL CUT
SUPERB MULCHING & GRASS CLIPPING DISTRIBUTION
STRENGTH, COMFORT & VERSATILITY MEET FINESSE
3.2 M MÜTHING® CUTTING WIDTH FOR LONGER GRASS
Technical Specs
Choose a Section
Key Attributes
Cutting Units
Traction, Brakes and Speed
Weight and Dimensions
Key Attributes
Cutting Units
Traction, Brakes and Speed
Weight and Dimensions
| Mower Cutting Width | 126" (3.2 m) |
| Mower Height of Cut | 1.2 - 2.8" (30 - 70 mm) |
| Cutting Units | 1 x 63" (1600 mm) front flail unit, two 39" (1000 mm) wing flails; 12.5" (300 mm) working diameter |
| Mower Engine | Kubota V2403 4-Cylinder, turbo diesel 65.2 HP (48.6 kW) |
| Cutting Capacity | 8.5 acre/hr at 7.5 mph (3.46 ha/hr at 12 kph) |
| Fuel/Battery Capacity (+Run Time) | 20.4 gal. (77.1 L) |
| Transport Speed | 15 mph (25 kph) |
| Mower Warranty | 2 Years |
| Number and Size | 1 x 63" (1600 mm) front flail unit, two 39" (1000 mm) wing flails; 12.5" (300 mm) working diameter |
| Blade Material | M Type heavy duty Carbide Flails with shark fin shredding bar for optimum spread and mulching of clippings. High strength structural steel hood with replaceable wear plate. Spring steel projectile guards. Bolt on carbide wear skids |
| Cutting Unit Lift | Fingertip operated joysticks for individual unit lift/lower; cross cut position. Electronic transport locks. |
| Traction Drive | Hydrostatic, automatic on-demand cross-flow 4WD in forward and on-demand in reverse |
| Reel Drive | Three dedicated cutter pumps to hydraulic motors with mechanical dual V belt final drive |
| Hydraulic System | 13.3 gal. (50.2 L) capacity regulated with side by side cooler |
| Service Brakes | Dynamic braking through hydrostatic traction system |
| Parking Brakes | Zero-maintenance electro-hydraulic wet parking brakes |
| Steering | Hydraulic power steering with adjustable tilt steering wheel |
| Mowing Speed | 10 mph (16.4 kph) electronically adjustable |
| Reverse Speed | 4 mph (6.4 kph) |
| Weight | 4,429 lbs. (2,009 kg), 4,808 lbs. (2,181 kg) with cab |
| Length (less catchers) | 148" (3.76 m) front deck down |
| Overall Height (including ROPS) | 83" ROPS up; 67" ROPS and decks down; 87" with cab (2.11 m ROPS up; 1.70 m ROPS and decks down; 2.2 m with cab) |
| Wheel Base | 65" (1.65 m) |
| Transport Width | 83” (2.1 m) |
| Working Width | 137" (3.5 m) with Muthing® flail units down |
